Small Cell Antenna Matrix

Filter:
Submit Search



Newly released products

  Frequency (MHz)   H-Beam Antenna Port Configuration   Model   Patterns   Bracket   Gain (dBi)   V-Beam °

L x D
(inches)
617-697 698-798 799-894 894-960 1695-2180 2180-2200 2200-2360 2360-2690 3400-3550 3550-3700 3700-3980 3980-4200 5150-5925
1695-2690 & 3700-4200 360° Omni Clover with 3 GHz Beamforming         4     8

CX12OMI236-BFx

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 9.9 & 14.4 13.3 & 9.4 24.0 L x 14.6 D
698-960 & 1695-2690 & 3400-4200 360° Omni Clover   4 4 8

CX16OMI236-2Cx 		Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 3.5 & 10.4 & 9.1 72.3 & 13 & 22 24.0 L x 14.6 D
1695-2690 & 3700-4200 360° Omni Clover with 3 GHz Beamforming         8     8

CX16OMI236-BFxy 		Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 7.4 & 14.4 27.5 & 9.4 24.0 L x 14.6 D
1695-2690 & 3400-3700 & 3700-3980 360° Omni Clover with 3 GHz Beamforming         8 4 8

CX20OMI236-1Cxy

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 7.4 & 7.6 & 14.4 26.8 & 33 & 9.4 30.0 L x 14.6 D
617-894 & 1695-2690 &3400-4200 360° Omni Clover 4   12 8

CYL2Q24GR-20xyz 		Contact Customer Service See Small Cell Solutions & Mounting Brackets Below see data sheet see data sheet 24.0 L x 14.6 D



  Frequency (MHz)   H-Beam Antenna Port Configuration   Model   Patterns   Bracket   Gain (dBi)   V-Beam °

L x D
(inches)
617-697 698-798 799-894 894-960 1695-2180 2180-2200 2200-2360 2360-2690 3400-3550 3550-3700 3700-3980 3980-4200 5150-5925

698-960 & 1695-2690

360° Omni Clover

   2 4

CX06OMI236-1C (RET)

Download

See Small Cell Solutions & Mounting Brackets Below

5.6 & 9.3

37.0 & 13.7

29.4 L x 14 D

1695-2180

360° Omni Clover

         4

CX04OMI536-1C

Download

See Small Cell Solutions & Mounting Brackets Below

11.9

7.3

66.0 L x 14 D

698-894 & 1695-2180

 360° Omni Clover   2   4                 CX06OMI436-0C (0° LB FET, HB RET)CX06OMI436-8C (8° LB FET, HB RET) Download

See Small Cell Solutions & Mounting Brackets Below

8.3 & 12.1

18.1 & 7.1

48.0 L x 14 D

698-960 & 1695-2690

360° Omni Clover

   4 4

CX08OMI236-3C (RET)

Download

See Small Cell Solutions & Mounting Brackets Below

3.5 & 9.9

71.5 & 14.4

29.4 L x 14 D
1695-2690 & 3700-4200 360° Omni Clover         4     8

CX12OMI236-BFx

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 9.9 & 14.4 13.3 & 9.4 24.0 L x 14.6 D

1695-2180

65° Tri-Sector

         12

CX12TRI565-1T

Download

See Small Cell Solutions & Mounting Brackets Below

16.5

7.3

66.0 L x 14 D

698-960 & 1695-2690 & 3550-3700 & 5150-5925

360° Omni Clover

   2 4   4     4

CX14OMI236-1C

Download

See Small Cell Solutions & Mounting Brackets Below

5.0 & 9.7 & 5.0 & 5.5

32.0 & 13.2 & 28.0 & 20.0

35.4  L x 14 D
1695-2690 & 3700-4200 360° Omni Clover         8     8

CX16OMI236-Bfxy 		Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 7.4 & 14.4 27.5 & 9.4 24.0 L x 14.6 D

698-960 & 1695-2690 & 3550-3700 & 5150-5925

360° Omni Clover

   4 4   4     4

CX16OMI236-1C

Download

See Small Cell Solutions & Mounting Brackets Below

3.5 & 9.7 & 5.0 & 5.5

72.0 & 13.2 & 28.0 & 20.0

35.4 L x 14 D
698-960 & 1695-2690 & 3550-3700 & 5150-5925 180° Omni Peanut   4 4   4     4 CX16OMI218-1P Download See Small Cell Solutions & Mounting Brackets Below 3.7 & 9.9 & 5.3 & 5.5 76.0 & 13.3 & 28.0 & 22.0 35.4 L x 14 D
698-960 & 1695-2690 & 3550-3700 & 5150-5925 240° Omni Heart   4 4   4     4 CX16OMI224-1H Download See Small Cell Solutions & Mounting Brackets Below 3.8 & 10.4 & 6.1 & 4.2 66.5 & 13.5 & 29.0 & 28.9 35.4 L x 14 D
698-960 & 1695-2690 & 3400-4200 360° Omni Clover   4 4 8

CX16OMI236-2Cx 		Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 3.5 & 10.4 & 9.1 72.3 & 13 & 22 24.0 L x 14.6 D
1695-2690 & 3400-4200 360° Omni Clover         8 8

CX16OMI236-3Cxy

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 8.1 & 9.3 18.7 & 8.4 24.0 L x 11.8 D
698-960 & 1695-2690 & 3400-4200 & 5150-5925 360° Omni Clover   4 8 4 2 CX18OMI236-1Cxy Download See Small Cell Solutions & Mounting Brackets Below 3.2 & 7.8 & 5.5 & 5.1 77.0 & 26.0 & 33.0 & 21.0 24.0 L x 14.6 D

698-960 & 1695-2690

90° & 65° each Sector

   6 12

CX18TRI265-5T (RET)

Download

See Small Cell Solutions & Mounting Brackets Below

8.8 & 14.7

32.0 & 13.1

29.4 L x 14 D
1695-2690 & 3400-3700 & 3700-3980 360° Omni Clover with 3 GHz Beamforming         8 4 8

CX20OMI236-1Cxy

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 7.4 & 7.6 & 14.4 26.8 & 33 & 9.4 30.0 L x 14.6 D
698-960 & 1695-2690 & 3400-4200 360° Omni Clover   4 8 8

CX20OMI236-3Cxy

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 2.4 & 7.1 & 7.8 82.4 & 26.6 & 8.4 24 L x 14.6 D
698-960 & 1695-2690 & 3400-4200 240° Heart   4 8 8

CX20OMI224-3Hxy

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 3.6 & 8.5 & 9.3 66 x 26.8 & 19.2 24 L x 14.6 D
698-960 & 1695-2690 & 3400-4200 180° Peanut   4 8 8

CX20OMI218-3Pxy

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 3.4 & 8.4 & 9.2 77.2 & 27.4 & 19.1 24 L x 14.6 D
698-960 & 1695-2700 & 3400-4200 65°   4 8 8

CX20OMI265-3Sxy

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 7.6 & 11.8 & 13.1 77.0 x 26.3 & 20.6 24 L x 14.6 D

698-960 & 1695-2690

92° & 70° each Sector

   12 12

CX24TRI265-5T (RET)

Download

See Small Cell Solutions & Mounting Brackets Below

6.1 & 14.5

74.0 & 13.0

29.4 L x 14 D



  Frequency (MHz)   H-Beam Antenna Port Configuration   Model   Patterns   Bracket   Gain (dBi)   V-Beam °   L x W x D (inches)
617-697 698-798 799-894 894-960 1695-2180 2180-2200 2200-2360 2360-2690 3400-3550 3550-3700 3700-3980 3980-4200 5150-5925

1695-2690 & 3400-4200 & 5150-5925

360° Omni Clover

         8 4 4

CYL2Q16GR-1xy

Download

See Small Cell Solutions & Mounting Brackets Below

see data sheet

see data sheet

24.2 L  x 14.6 D

698-960 & 1695-2690 & 3400-4200 & 5150-5925

360° Omni Clover

   4 8 4 2

CYL2Q18GR-1xy

Download

See Small Cell Solutions & Mounting Brackets Below

see data sheet

see data sheet

24.2 L  x 14.6 D
698-960 & 1695-2690 & 3400-4200 360° Omni Clover   4 12 8

CYL2Q24GR-1xyz

Download See Small Cell Solutions & Mounting Brackets Below see data sheet see data sheet 24.2 L  x 14.6 D
617-894 & 1695-2690 &3400-4200 360° Omni Clover 4   12 8

CYL2Q24GR-20xyz

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below see data sheet see data sheet 24.0 L x 14.6 D
698-960 & 1695-2698 & 3400-4200 & 5150-5925 360° Omni Clover   4 12 4 4 CYL4Q24GR-1xyz Download See Small Cell Solutions & Mounting Brackets Below see data sheet see data sheet 48.0 L  x 14.6 D



  Frequency (MHz)   H-Beam Antenna Port Configuration   Model   Patterns   Bracket   Gain (dBi)   V-Beam °   L x W x D (inches)
617-697 698-798 799-894 894-960 1695-2180 2180-2200 2200-2360 2360-2690 3400-3550 3550-3700 3700-3980 3980-4200 5150-5925
1695-2690 & 3550-3700 & 5150-5925 60°         4   4     2

DX10FRO260-00/06

Download 91900324 14.0 & 15.5 & 5.5 14 & 9 & 26° 24.0 x 15.0 x 3.75
698-894 & 1695-2690 & 3550-3700 & 5150-5925 60°   2   4   4     2

DX12FRO260-20/26

Download 91900324 10.0 & 14.0 & 15.0 & 5.5 33 & 14 & 9 & 26° 24.0 x 15.0 x 5.25
1695-2690 & 3400-3700 & 3700-4200 65°         8 4 8   DX20FRO265-01 Contact Customer Service 91900318 10.8 & 13.0 & 21.6 35 & 21 & 6.8 30.0 x 14.2 x 8.5
698-960 & 1695-2690 & 3400-4200 65°   4 8 8   DX20FRO265-04 Contact Customer Service 91900324 7.4 & 12.4 & 14.0 72 & 25 & 21.5 24.0 x 14.2 x 8.5
698-960 & 1695-2690 & 3400-4200 65°   4 12 8   DX24FRO265-04 Contact Customer Service 91900324 7.2 & 10.7 & 13.9 72 & 40 & 21.5 24.0 x 14.2 x 8.5
3400-3700 65°                 2

SX02FIT165-20

Contact Customer Service

919050

13.5 19.7 13.1 x 6.7 x 3.3
3700-4200 65°                     4

MX04FIT265-01

Contact Customer Service 91900318 16.0 8.0 24 x 11.6 x 4.5
3550-3700 45°                   4       MX04FIT345-01 Download 91900318 19.0 7.3 32.67 x 11.6 x 4.53
3550-3700 65°                   4       MX04FIT365-01 Download 91900318 17.0 7.3 32.67 x 11.6 x 4.53
698-894 & 1695-2180 60°   2   4

X7CQAP-FRO-260

Download

919017 		10.9 & 15.4 42°& 15.4° 24.1 x 18.8 x 6.3

698-960 & 1695-2690

65°

   2 2

XGU-465

Download

919011

15.5 & 17.3

17.5° & 7.5°

50.5 x 14.6 x 8.2
617-894 &
1695-2200 		65° 4   4

MX08FRO265-20

Contact Customer Service 91900324 8.5 & 13.8 39.5 & 15.4 24 x 20 x 8
617-894 & 1695-2690 & 3400-4200 30° 2

SX04FRO230-01

Contact Customer Service 91900324 13 & 14.6 & 14.6 & 13.8 35.4 & 27.5 & 37 & 40 24 x 24 x 8.5
                  2

617-2690 & 3400-4200 & 5150-5925

30°

 2 4 2 SX08FRO230-01

Download

91900324 13.0 & 14.6 & 14.1 & 5.5 35.4 & 27.5 & 37 & 33.5 24.0 x 24.0 x 8.5



Small cell solutions and mounting brackets

SC-BKT-SA-(color)

Side Arm Mounting System

SC-BKT-SKTCX-(color)

Side Arm Mount Cable Concealment Shroud for CX antennas

SC-BKT-SLA-(color)

Steel Pole Mounting System
SC-BKT-SHRCX-(color) Steel Pole Mount Cable Concealment Shroud

SC-BKT-WTPE-(color)

 Wide Diameter Pole Mounting System
SC-BKT-WSACX-(color) Wide Diameter Pole Mount Cable Concealment Shroud



Antenna brackets and mounting hardware

91900324

BRACKET KIT, INSTALLATION, DX ANTENNA, STADIUM ANTENNA, ROTATIONAL

919011

BRACKET KIT, INSTALLATION,  2-POINT, 12 DEG D-TILT

919017

BRACKET KIT, INSTALLATION,  2-POINT, 22 DEG D-TILT

919050

BRACKET KIT, INSTALLATION,  VENUE ANTENNA



Installation guide

81900510

Venue Bracket Antenna Installation Guide for 919050 and 919055 bracket kits
81900511 Venue Bracket Antenna Installation Guide for 91900324 and 91900325 bracket kits
