Brackets Matrix
| Antenna Brackets & Mounting Hardware | |
|---|---|
|
BRACKET KIT, INSTALLATION, STADIUM ANTENNA (TILT & AZIMUTH EXTENSION) |
|
|
BRACKET KIT, DUAL ANTENNA MOUNT |
|
|
BRACKET KIT, TOP AND BOTTOM, FOUR-, SIX- & EIGHT-FOOT ANTENNAS |
|
|
BRACKET KIT, CENTER, EIGHT-FOOT ANTENNAS |
|
| BRACKET KIT, INSTALLATION, DX ANTENNA, STADIUM ANTENNA, ROTATIONAL | |
| BRACKET KIT, INSTALLATION, MX08FIT265-01 EXTENSION | |
|
BRACKET KIT, INSTALLATION, 2-POINT, 12 DEG D-TILT |
|
|
|
BRACKET KIT, INSTALLATION, 2-POINT, 22 DEG D-TILT |
|
|
BRACKET KIT, INSTALLATION, 3-POINT, 6 DEG D-TILT |
|
|
BRACKET KIT, INSTALLATION, 2-POINT, 9 DEG D-TILT |
|
BRACKET KIT, INSTALLATION, VENUE ANTENNA |
|
|
BRACKET KIT, INSTALLATION, VENUE ANTENNA (INVERTED MOUNT) |
|
| Small cell solutions and mounting brackets | ||||||||
|---|---|---|---|---|---|---|---|---|
|
Side Arm Mounting System |
||||||||
| Side Arm Mount Cable Concealment Shroud | ||||||||
|
Steel Pole Mounting System |
||||||||
| Steel Pole Mount Cable Concealment Shroud | ||||||||
|
Wide Diameter Pole Mounting System |
||||||||
| Wide Diameter Pole Mount Cable Concealment Shroud | ||||||||
| Installation guides | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Dual Mount Bracket Installation Guide for 91900314 bracket kit | ||||||||||
|
NWAV Macro Antenna Bracket Installation Guide |
||||||||||
|
Venue Bracket Antenna Installation Guide for 919050 and 919055 bracket kits |
||||||||||
| Venue Bracket Antenna Installation Guide for 91900324 and 91900325 bracket kits | ||||||||||
| IV0XOMI136 Antenna Installation Guide for ceiling-mount antenna | ||||||||||
| SV02UTS136-PT Under-the-Seat Antenna Installation Guide | ||||||||||
| 81900520 | IV0XOMI136-T4 Antenna Installation Guide for ceiling-mount antenna | |||||||||
| Instructions for Extension Kit for MX08FIT265-01 antenna | ||||||||||
RET accessories
| Primary Control Unit for Remote Electrical Tilt and RET motor | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
|
Primary control unit for Remote Electronic Tilt AISG v2.0 |
||||||||||
|
RET Motor Assembly, AISG 2.0 |
||||||||||
| Smart Bias Tee - Top | Smart Bias Tee for AISG injection into antenna RF port | |||||||||
| PCU-1000 downloads |
|---|
| RET Controller Software Download |
| USB Driver for AISG Controller |
| PCU-1000 User Guide |
| MOP PCU-220 User Guide |
| AISG cables | ||
|---|---|---|
| AISG Cables datasheet | ||
| Part Number | Description | Weight |
|
992100-CA005-SC |
AISG Jumper Cable, M/F, 0.5 meters |
.300 lb |
|
992100-CA010-SC |
AISG Jumper Cable, M/F, 1.0 meters |
.402 lb |
|
992100-CA013- SC |
AISG Jumper Cable, M/F. 1.3 meters. |
.532 lb |
|
992100-CA020-SC |
AISG Jumper Cable, M/F, 2.0 meters |
.590 lb |
|
992100-CA030-SC |
AISG Jumper Cable, M/F, 3.0 meters | .778 lb |
|
992100-CA040-SC |
AISG Jumper Cable, M/F, 4.0 meters |
.964 lb |
|
992100-CA050-SC |
AISG Jumper Cable, M/F, 5.0 meters |
1.182 lb |
|
992100-CA060-SC |
AISG Jumper Cable, M/F, 6.0 meters |
1.364 lb |
|
992100-CA080-SC |
AISG Jumper Cable, M/F, 8.0 meters |
1.896 lb |
|
992100-CA100-SC |
AISG Jumper Cable, M/F, 10.0 meters |
2.295 l |
|
992100-CA120-SC |
AISG Jumper Cable, M/F, 12.0 meters |
2.694 lb |
|
992100-CA200-SC |
AISG Jumper Cable, M/F, 20.0 meters |
6.586 lb |
|
992100-CA300-SC |
AISG Jumper Cable, M/F, 30.0 meters |
7.804 lb |
|
992100-CA400-SC |
AISG Jumper Cable, M/F, 40.0 meters |
9.022 lb |
|
992100-CA500-SC |
AISG Jumper Cable, M/F, 50.0 meters |
10.240 lb |
|
992100-CA600-SC |
AISG Jumper Cable, M/F, 60.0 meters |
11.458 lb |
|
992100-CA700-SC |
AISG Jumper Cable, M/F, 70.0 meters |
12.676 lb |
|
992100-CA800-SC |
AISG Jumper Cable, M/F, 80.0 meters |
13.894 lb |
|
992100-CA900-SC |
AISG Jumper Cable, M/F, 90.0 meters |
15.112 lb |
|
992100-CA1000-SC |
AISG Jumper Cable, M/F, 100.0 meters |
16.330 lb |
