Beamforming Antenna Matrix

Filter:
Submit Search



Newly release products

  Frequency (MHz)   H-Beam Antenna Port Configuration   Model   Patterns   Bracket   Gain (dBi)   V-Beam °

L x D
(inches)
617-697 698-798 799-894 894-960 1695-2180 2180-2200 2200-2360 2360-2690 3400-3550 3550-3700 3700-3980 3980-4200 5150-5925
1695-2690 & 3700-4200 360° Omni Clover         4     8

CX12OMI236-BFx

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 9.9 & 14.4 13.3 & 9.4 24.0L x 14.6D
1695-2690 & 3700-4200 360° Omni Clover         8     8

CX16OMI236-BFxy

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 7.4 & 14.4 27.5 & 9.4 24.0L x 14.6D
1695-2690 & 3400-3700 & 3700-3980 360° Omni Clover with 3 GHz Beamforming         8 4 8

CX20OMI236-1Cxy

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 7.4 & 7.6 & 14.4 26.8 & 33 & 9.4 30.0 L x 14.6 D

Macro Antennas

Frequency (MHz)  H-Beam Antenna Port Configuration  Model  Patterns  Bracket  Gain (dBi)  V-Beam °  L x W x D (inches)
617-697 698-798 799-894 894-960 1695-2180 2180-2200 2200-2360 2360-2690 3400-3550 3550-3700 3700-3980 3980-4200 5150-5925
698-894 &
1695-2180 & 3700-4200 		45°   2   4           8

MX14FRO445-01

Contact Customer Service

91900318

14.6 & 17.6 & 19.5 17.2 & 7.4 & 7.5 55 x 20 x 8
698-894 &
1695-2180 & 3700-4200 		45°   2   4           8

MX14FRO645-01

Contact Customer Service

91900318

16.5 & 19.6 & 19.5 12.5 & 5.7 & 7.5 72 x 20 x 8
698-894 &
1695-2180 & 3700-4200 		45°   2   4           8

MX14FRO845-01

Contact Customer Service

91900318 & 91900319

17.6 & 20.0 & 19.9 8.7 & 5.7 & 7.5 96 x 20 x 8
698-894 &
1695-2180 & 3700-4200 		60°   2   4           8

MX14FRO460-01

Contact Customer Service

91900318

13.7 & 17.0 & 19.5 16.8 & 7.5 & 7.5 55 x 14.2 x 8.5
698-894 &
1695-2180 & 3700-4200 		60°   2   4           8   MX14FRO660-01 Contact Customer Service

91900318

14.9 & 17.9 & 19.5 13 & 5.3 & 7.5 72 x 14.2 x 8.5
698-894 &
1695-2180 & 3700-4200 		60°   2   4           8   MX14FRO860-01 Contact Customer Service

91900318 & 91900319

16.5 & 17.9 & 19.9 8.4 & 5.3 & 7.5 96 x 14.2 x 8.5
698-894 &
1695-2180 & 3700-4200 		65°   2   4           8

MX14FIT465-01

Contact Customer Service

91900318

13.5 & 16.8 & 19.5 16.8 & 7.5 & 7.5 54 x 14.2 x 8.5
698-894 &
1695-2180 & 3700-4200 		65°   2   4           8   MX14FIT665-01 Contact Customer Service

91900318

14.7 & 17.7 & 19.5 13.0 & 5.3 & 7.5 72 x 14.2 x 8.5
698-894 &
1695-2180 & 3700-4200 		65°   2   4           8   MX14FIT865-01 Contact Customer Service

91900318 & 91900319

15.9 & 17.7 & 19.9 8.4 & 5.3 & 7.5 96 x 14.2 x 8.5
3700-4200 65°                     8   MX08FIT265-01 Contact Customer Service

91900330

21.0 6.2 32 x 11.6 x 4.5

Small Cell Antennas

  Frequency (MHz)   H-Beam Antenna Port Configuration   Model   Patterns   Bracket   Gain (dBi)   V-Beam °

L x D
(inches)
617-697 698-798 799-894 894-960 1695-2180 2180-2200 2200-2360 2360-2690 3400-3550 3550-3700 3700-3980 3980-4200 5150-5925
1695-2690 & 3700-4200 360° Omni Clover with 3 GHz Beamforming         4     8

CX12OMI236-BFx

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 9.9 & 14.4 13.3 & 9.4 24.0L x 14.6D
1695-2690 & 3700-4200 360° Omni Clover with 3 GHz Beamforming         8     8

CX16OMI236-BFxy

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 7.4 & 14.4 27.5 & 9.4 24.0L x 14.6D
1695-2690 & 3400-3700 & 3700-3980 360° Omni Clover with 3 GHz Beamforming         8 4 8

CX20OMI236-1Cxy

Contact Customer Service See Small Cell Solutions & Mounting Brackets Below 7.4 & 7.6 & 14.4 26.8 & 33 & 9.4 30.0 L x 14.6 D
1695-2690 & 3400-3700 & 3700-4200 65°         8 4 8   DX20FRO265-01 Contact Customer Service 91900318 10.8 & 13.0 & 21.6 35 & 21 & 6.8 30.0 x 14.2 x 8.5



Macro antenna brackets and mounting hardware

91900314

BRACKET KIT, DUAL ANTENNA MOUNT

91900318

BRACKET KIT, TOP AND BOTTOM, FOUR-, SIX- & EIGHT-FOOT ANTENNAS

91900319

BRACKET KIT, CENTER, EIGHT-FOOT ANTENNAS

91900330

BRACKET KIT, INSTALLATION, MX08FIT265-01 EXTENSION



Small cell solutions and mounting brackets

SC-BKT-SA-(color)

Side Arm Mounting System

SC-BKT-SKTCX-(color)

Side Arm Mount Cable Concealment Shroud for CX antennas

SC-BKT-SLA-(color)

Steel Pole Mounting System
SC-BKT-SHRCX-(color) Steel Pole Mount Cable Concealment Shroud

SC-BKT-WTPE-(color)

 Wide Diameter Pole Mounting System
SC-BKT-WSACX-(color) Wide Diameter Pole Mount Cable Concealment Shroud



Installation guides
81900506 Dual Mount Bracket Installation Guide for 91900314 bracket kit

81900507

NWAV Macro Antenna Bracket Installation Guide

81900523

Instructions for Extension Kit for MX08FIT265-01 antenna



Primary Control Unit for Remote Electrical Tilt and RET Motor

PCU-1000

 Primary control unit for Remote Electronic Tilt AISG v2.0



PCU-1000 downloads

RET Controller Software Download

USB Driver for AISG Controller

PCU-1000 User Guide
